Specifications
Please note - specifications subject to change without prior notice.
| FRAME | eSPRESSO CC LITE III; MAT aluminium; 27,5x2,25" max. WHS; 135x9 AST; internal |
| SHOCK | |
| FORK | Suntour NVX30 DS; Coil; 80 STR; 27,5x2,4" max WHS |
| BRAKE-F | Shimano MT-200; 2 piston |
| BRAKE-R | Shimano MT-200; 2 piston |
| ROTOR-FRONT | Shimano RT10; 180 mm |
| ROTOR-REAR | Shimano RTEM300M; 180 mm |
| CHAIN | Shimano LG500 |
| CHAINGUARD | Sunnywheel SW-CG-173A |
| CRANKSET | Samox NWP203 ; 38 ATC |
| CRANK SIZE | MERIDA EXPERT TK; 165mm |
| DERAILLEUR-FRONT | |
| DERAILLEUR-REAR | Shimano CUES U4000 |
| FREEWHEEL | Shimano LG300; 11-46 ATC; 9 GER |
| PEDAL | VP VPE-891 |
| GRIP | MERIDA EXPERT TK |
| HANDLEBAR | MERIDA EXPERT; MAT aluminium; 660 WHB; 15 RHB |
| STEM | MERIDA EXPERT CT; MAT aluminium; 31.8 DSH; adjustable |
| STEM SIZE | 90 mm- XS/S/M/L/XL |
| HEADSET | MERIDA-8254 |
| HUB-F | Shimano QC300; 100x9 WHF; 32 SPH; Centerlock |
| HUB-R | Shimano QC300; 135x9 WHR; 32 SPH; Centerlock |
| AXLE-F | |
| AXLE-R | |
| SADDLE | MERIDA EXPERT TK II; V-mount |
| SEAT CLAMP | MERIDA EXPERT |
| SEAT POST | JD-SP79; 30.9 DSP; 15 SSB; 40 SST |
| SHIFTER-F | |
| SHIFTER-R | Shimano CUES U4000 |
| SPOKE | Black stainless |
| TIRE-F | Maxxis Crossmark II; 27.5x2.25"; wire; reflecting line |
| TIRE-R | Maxxis Crossmark II; 27.5x2.25"; wire; reflecting line |
| CARRIER | MERIDA MIK HD Carrier with Spring clip & Spanninga rear light |
| FENDER | Sunnywheel SW-FA-311-65(MSB) |
| KICKSTAND | Atranvelo ED-100-PC |
| LIGHT-FRONT | Herrmans H-Black MR4 E |
| LIGHT-REAR | Spanninga Commuter Glow XE integrated in MERIDA MIK HD carrier |
| FRAME LOCK | Abus 4650 XL |
| DRIVE UNIT | Shimano EP6; 85Nm |
| DRIVE COVER | Drive Unit Cover for EP801/EP600 |
| BATTERY | Shimano EN805-L; 504Wh |
| SWITCH | |
| DISPLAY | Shimano SC-EN500 |
