Specifications

Please note - specifications subject to change without prior notice.

FRAME	eSPRESSO CC LITE III; MAT aluminium; 27,5x2,25" max. WHS; 135x9 AST; internal
SHOCK
FORK	Suntour NVX30 DS; Coil; 80 STR; 27,5x2,4" max WHS
BRAKE-F	Shimano MT-200; 2 piston
BRAKE-R	Shimano MT-200; 2 piston
ROTOR-FRONT	Shimano RT10; 180 mm
ROTOR-REAR	Shimano RTEM300M; 180 mm
CHAIN	Shimano LG500
CHAINGUARD	Sunnywheel SW-CG-173A
CRANKSET	Samox NWP203 ; 38 ATC
CRANK SIZE	MERIDA EXPERT TK; 165mm
DERAILLEUR-FRONT
DERAILLEUR-REAR	Shimano CUES U4000
FREEWHEEL	Shimano LG300; 11-46 ATC; 9 GER
PEDAL	VP VPE-891
GRIP	MERIDA EXPERT TK
HANDLEBAR	MERIDA EXPERT; MAT aluminium; 660 WHB; 15 RHB
STEM	MERIDA EXPERT CT; MAT aluminium; 31.8 DSH; adjustable
STEM SIZE	90 mm- XS/S/M/L/XL
HEADSET	MERIDA-8254
HUB-F	Shimano QC300; 100x9 WHF; 32 SPH; Centerlock
HUB-R	Shimano QC300; 135x9 WHR; 32 SPH; Centerlock
AXLE-F
AXLE-R
SADDLE	MERIDA EXPERT TK II; V-mount
SEAT CLAMP	MERIDA EXPERT
SEAT POST	JD-SP79; 30.9 DSP; 15 SSB; 40 SST
SHIFTER-F
SHIFTER-R	Shimano CUES U4000
SPOKE	Black stainless
TIRE-F	Maxxis Crossmark II; 27.5x2.25"; wire; reflecting line
TIRE-R	Maxxis Crossmark II; 27.5x2.25"; wire; reflecting line
CARRIER	MERIDA MIK HD Carrier with Spring clip & Spanninga rear light
FENDER	Sunnywheel SW-FA-311-65(MSB)
KICKSTAND	Atranvelo ED-100-PC
LIGHT-FRONT	Herrmans H-Black MR4 E
LIGHT-REAR	Spanninga Commuter Glow XE integrated in MERIDA MIK HD carrier
FRAME LOCK	Abus 4650 XL
DRIVE UNIT	Shimano EP6; 85Nm
DRIVE COVER	Drive Unit Cover for EP801/EP600
BATTERY	Shimano EN805-L; 504Wh
SWITCH
DISPLAY	Shimano SC-EN500
